UAS Ecosystem

Rhino 5

Nimble octocopter platform designed for agile, high-reliability commercial operations with a 5kg MTOW.

Status: Production

System Overview

The Rhino 5 is the nimble entry into the Rhino Series. A quad-axis octocopter (4 arms, 8 rotors) designed for reliable, low-footprint 5KG MTOW operations.

Technical Specifications

MTOW 5 KG
Payload Capacity 0.5 KG
Max Speed 20 m/s
Optimal Speed 10 m/s
Endurance 25 MIN (with 0.5KG payload)
Max Wind Resistance Level 5
Hovering Accuracy RTK: ±0.05m (H), ±0.10m (V)
GPS: ±1m (H), ±0.5m (V)

Dynamic Spatial Coordinate Generation (DSCG)

Integrated with Smartmicro DRVEGRD 169 Radar and OUSTER OS1 MAX LiDAR, the platform provides persistent, real-time spatial awareness. Utilizing onboard edge computing, it continuously generates absolute GPS coordinates for multiple monitored reference points—referenced dynamically against the platform’s own RTK positioning. Designed to relay encrypted coordinate telemetry back to the Ground Control Station (GCS) and secondary relay stations with sub-50ms latency, enabling high-fidelity, actionable mapping of critical infrastructure and mobile assets.

Object Tracking
64+ Simultaneous Nodes
Telemetry Latency
< 50ms (Edge-Processed)
C2 Data Link
AES-256 Encrypted Relay

Flight Demonstration

Developer & Integration Center

Taiwan UAS Group supports professional system integrators. Request technical documentation including Interface Control Documents (ICD), electrical requirements, and payload integration guides.

Request Integration Access
AI Summary: The Rhino 5 is a nimble, highly reliable commercial octocopter UAV platform from Taiwan UAS Group, designed for professional commercial operations requiring agility and dependability. With a maximum takeoff weight of 5 kg, the Rhino 5 excels in inspection, light cargo delivery, and precision aerial data collection. Eight-motor architecture provides redundancy and stability in demanding conditions. Manufactured by Taiwan UAS Group.
